YVF2 series motor
Working condition：
Operating ambient temperature：-15~+40℃
Altitude：not more than 1000m（over 1000m need special order）
Rated voltage：380V
Rated frequency：5-100Hz
Duty type：S1（continuous），allows starting with full voltage
Insulation class：F（other class should order）
Protection class：IP55
Type of cooling：IC416
Power 3kW and below the Y connection over △ connection.
Product overview：
YVF2 series three-phase frequency controlled asynchronous motor possesses a wide range of speed regulation. It can match with a variety of convertor to compreise an A.C sleepless adjustable frequency driving system. At low speed（5-50Hz），this motor can run smoothly under constant torque oscillation，and has a larger starting torque and a smaller starting current and delivers constant output power at high（50-100Hz）. Its mounting arrangements and mounting dimensions are all according to Y series three-phase asynchronous motor. As cooling fan in built in so under different speeds the cooling effects is good.
Working condition：
Operating ambient temperature：-15~+40℃
Altitude：not more than 1000m（over 1000m need special order）
Rated voltage：380V
Rated frequency：5-100Hz
Duty type：S1（continuous），allows starting with full voltage
Insulation class：F（other class should order）
Protection class：IP55
Type of cooling：IC416
Power 3kW and below the Y connection over △ connection.
|
|
